Cardinal 201 User Manual

Model 201 Installation & Technical
8400-M117-O1 Rev D
Page 143
15. PARTS IDENTIFICATION
15.1 Parts List (All Views)
ITEM NO.
QTY.
PART NUMBER
DESCRIPTION
1
1
593GR986
SERIAL TAG ASSY
2
6
6021-0654
SCW PAN-HEAD.
MACHINE-SCW 06-32X 0.25
3
2
6021-2071
SCW FILLISTER.
MACHINE-SCW 06-32X.25
4
2
6021-2045
SCW FLAT-HEAD.
MACHINE-SCW 06-32X.625
5
1
6600-1243
DIN RAIL MOUNTING CLIP, BLACK
6
8
6680-0004
WASHER LOCK INT TOOTH
#6 TYPE A Z-PL
7
1
8400-B105-0A
INTERNAL DISPLAY CABLE
8
1
8400-C112-08
BASE, INNER BOX
9
1
8400-C120-0A
FRONT PANEL REMOTE DISPLAY
10
1
8400-D100-0A
201 CONTROLLER BOARD
11
1
8400-D113-08
COVER, INNER BOX
15.1.1 201 Terminal Block Connectors

QTY.
PART NUMBER
DESCRIPTION
1
6610-1548
P2 – 10-pin ISO I/O Terminal Block Connector
1
6610-1546
P7 – 2-pin Power Terminal Block Connector
1
6610-1554
P8 – 7-pin Load Cell Terminal Block Connector
1
6610-1548
P9 – 10-pin Serial & Analog I/O Terminal Block
Connector

Not shown.
