Model 201 Installation & Technical
8400-M117-O1 Rev D
Page 21
4. WEIGHT TRANSMITTER SETUP (Metrological Parameters)
4.1 Calibration Switch
Your Model 201 weight transmitter has been thoroughly tested and
calibrated before being shipped to you. If you received the weight
transmitter attached to a scale, calibration is not necessary. If the weight
transmitter is being connected to a scale for the first time or recalibration
is necessary for other reasons, proceed as indicated.
The calibration switch is located on the main printed circuit board
and can only be accessed by removing the screw below and to the
right of the load cell connector. Refer to Figure No. 4.
Figure No. 4
P2 -Power
P8- Load Cell
P9 -Serial &
Analog I/O
