Model 201 Installation & Technical
8400-M117-O1 Rev D
4.4 Setup Mode
SETUP
With SETUP displayed, press the F3/ key. The display will change to USA=.
Proceed to the USA= (Domestic of International) parameter.
USA= (Domestic or International)
With USA= displayed, press the F3/ key to show the current setting. If
the setting displayed is acceptable, press the F3/ key again to save it.
Otherwise, use the F2/ key to toggle to a new setting and then press the
F3/ key to save it.
trL= (4% Zero Range) = no
trL=(4% Zero Range) = yes
CAP (Capacity) = + 4% to OC
CAP (Capacity) = + 9 grads to OC
LFt= (Legal For Trade)
Press the F3/ key to show the current setting. If the setting displayed is
acceptable, press the F3/ key again to save it. Otherwise, use the F2/
key to toggle to a new setting and then press the F3/ key to save it.
Interval Settings (Int=) allowed
are: 1, 2, 5, 10, 20, 50
Interval Setting (Int=) is
selectable from 1 to 99.
When both LFt=yes and USA=yes, the followings results occur:
Scale must have between 100 and 10,000 divisions
Inhibit serial data during input
trA= (Zero Tracking Range) = 0.5 or 0 to 3
trL= (4% Zero Range) = no
CAP (Capacity) = + 4% to OC
When LFt=yes and USA=no, the followings results occur:
trL= (4% Zero Range) = yes
CAP (Capacity) = + 9 grads to OC
