Model 201 Installation & Technical
8400-M117-O1 Rev D
Page 60
1p2 (IP Address, Second Part)
The format for an IP address is: ## . # . # . ## (e.g., 90.1.2.68).
This parameter is the second part of the address.
Press the F3/  key to view the current setting for the second
part of the IP address. If the displayed setting is acceptable,
press the F3/  key to save it. Otherwise, use the F2/ and
F1/ keys to enter a new setting and press the F3/  key to
save the new setting. Allowable values are: 000 through 255.
Ip3 (IP Address, Third Part)
The format for an IP address is: ## . # . # . ## (e.g., 90.1.2.68).
This parameter is the third part of the address.
Press the F3/  key to view the current setting for the third part
of the IP address. If the displayed setting is acceptable, press
the F3/  key to save it. Otherwise, use the F2/ and F1/
keys to enter a new setting and press the F3/  key to save the
new setting. Allowable values are: 000 through 255.
Ip4 (IP Address, Fourth Part)
The format for an IP address is: ## . # . # . ## (e.g., 90.1.2.68).
This parameter is the fourth part of the address.
Press the F3/  key to view the current setting for the fourth part
of the IP address. If the displayed setting is acceptable, press
the F3/  key to save it. Otherwise, use the F2/ and F1/
keys to enter a new setting and press the F3/  key to save the
new setting. Allowable values are: 000 through 255.
nET1 (Netmask, First Part)
The format for the Netmask is: ### . ### . ### . # (e.g.,
255.255.252.0). This parameter is the first part of the Netmask.
Press the F3/  key to view the current setting for the first part of
the Netmask. If the displayed setting is acceptable, press the
F3/  key to save it. Otherwise, use the F2/ and F1/ keys to
enter a new setting and press the F3/  key to save the new
setting. Allowable values are: 000 through 255.
