Symbol
Name
Description

OUT1
DIGITAL
OUTPUT
This annunciator is used to signal
that a digital output (the function it
was assigned during the setup of the
Digital Input/Output parameter) has
been activated.

OUT2
DIGITAL
OUTPUT
This annunciator is used to signal
that a digital output (the function it
was assigned during the setup of the
Digital Input/Output parameter) has
been activated.

OUT3
DIGITAL
OUTPUT
This annunciator is used to signal
that a digital output (the function it
was assigned during the setup of the
Digital Input/Output parameter) has
been activated.

OUT4
DIGITAL
OUTPUT
This annunciator is used to signal
that a digital output (the function it
was assigned during the setup of the
Digital Input/Output parameter) has
been activated.
