CAS CL5000 Series - Display Test (Menu Code 1861); AD Test (Menu Code 1862); Keyboard Test (Menu Code 1863); Chess Printer Test (Menu Code 1864)

113
2.14.14 Display Test (Menu code 1861)
(MENU -> 8. SCALE CONFIG -> 6.Test -> 1. Display )
2.14.15 A/D Test (Menu code 1862)
(MENU -> 8. SCALE CONFIG -> 6.Test -> 2. A/D)
2.14.16 Keyboard Test (Menu code 1863)
(MENU -> 8. SCALE CONFIG -> 6.Test -> 3. Keybord)
To test keyboard, press “3” on Test menu screen.
2.14.17 Chess Printer Test (Menu code 1864)
(MENU -> 8. SCALE CONFIG -> 6.Test -> 4. Chess Print)
To test the display, press “1” on Test menu
screen. It automatically tests it. User may exit
from testing, using “X/ESC” key.
Press “TEST” key to test printing a label.
User may exit from this menu, using “X/ESC”
key.
CHESS PRINT (1/1)
[TEST] = Print Test
[ESC] = Escape
To test the A/D, press “2
”
on Test menu screen.
To set zero press “ZERO”
User may exit from this menu, using “X/ESC” key
ZERO
KEYBOARD TEST (1/1)
Raw Code:[006C]
To exit keyboard test, press “ESC
”
two times.
0
0
19327
1862
A
D TEST (1/1)
Normalized A/D
