CAS CL5000 Series - Page 56

56

The following defines the format characters for Barcode Formats : (Example)
Form No. Format Description
0 User Defined Barcode
1 DDIIIIIPPPPPC
2 DDIIIIPPPPPPC
3 DIIIIIPPPPPPC
4 DIIIIIIPPPPPC
z I: item code
z N: PLU number
z P: price
z V: price check digit
(It is created automatically)
z U: unit price
z W: weight
z Q: quantity
z D: department
z G: group
z K: country code (For future)
z A: ticket counter (Only for ticket)
z B: scale transaction counter
z C: total barcode check sum
(It is created automatically)
z F: PLU prefix character
z T: text character
z R: transaction counter for each PLU
z L: clerk number
z S: weight code(Swedenish)
z J: swedenish total price
z %: print next fixed character
*
z 0~9: numbers
*%: It is used to enter characters therefore you cannot use this to enter numbers.
4. Enter Barcode Form
You can select from a list of Barcode types or
you can create your own custom format
* Refer to below table.
EX) Barcode Form = 1. Change DDIIIIIPPPPPC
to GGIIIIIVPPPPC
NEW/EDIT BARCODE (2/2)
Type : [ 1] EAN-13
Form (0~4) : [1]
DDIIIIIPPPPPC
PRINT
1
PRINT
G G
BARCODE NO. 1 : 1 (2/2)
Type : [ 1] EAN-13
From (0~4) : [1]
[GGIIIIIPPPPPC ]
4. Exit Menu
If you want to exit, press “ESC” key.
X
ESC
