3-CONTROLSANDINSTRUMENTS

(12)H/ISOcontrolpatternselector,ifequipped

Thisselectsthedrivepatterntypeofhand

controloperation.Readthepropersteps

listedinthischaptertoactivate.

(13)WORKLIGHTS

Thisknobcontrolstheexternalworking

lightsandroadlights.Worklightswitch

positions:

•

(1)-AlllightsOFF .

•

(2)-FrontworklightsON,sideworklights

OFF,rearworklightsON,rearredlights

OFF.

•

(3)-FrontworklightsON,sideworklights

OFF,rearworklightsOFF ,rearredlights

ON.

•

(4)-FrontworklightsON,sideworklights

ON,rearworklightsON,rearredlights

OFF.

931093305

3-46
