CASE CONSTRUCTION Alpha Series - Moving the Machine

300 pages

Save Page as PDF

To Next Page

To Previous Page

3-CONTROLSANDINSTRUMENTS

Movingthemachine

Pushboththeleft-handcontrollever(1)andtheright-

handcontrollever(2)forward,fromneutral,tomovethe

machineforward.Pullbothofthecontrolleversrear-

wardfromneutral,tomovethemachineinreverse.Move

thecontrolleversforwardashortdistanceformaximum

powerandslowspeed.Movethecontrolleverscom-

pletelyforwardformaximumspeed.

MovebothcontrolleverstoNEUTRALtostopmovement

ofthemachine.

93109347C1

3-15
