3-CONTROLSANDINSTRUMENTS

Machinelights

Activatethecabexteriorlights(ifequipped)byarotary

switch(1)onthebottomoftheright-handinstrument

panel.Therotaryswitch(1):

•

remainsinthelastpositionthatyouselect.

•

willnotfunctionwithoutthekey(Machinesequipped

withtheElectronicInstrumentCluster(EIC)).

•

willnotfunctionwithoutthePOWERbuttonengaged

(MachinesequippedwiththeAdvancedInstrument

Cluster(AIC)).

931007504A1

Therotaryswitch(1)hasfourpositions

PositionFront

work

light

Side

work

lights

Rear

work

lights

Rearred

lights

(1)OFFOFFOFFOFF

(2)ONOFFONOFF

(3)ONOFFOFFON

(4)ONONONOFF

844122902

3-69
