3-CONTROLSANDINSTRUMENTS
MECHANICALHYDRAULICCONTROLS
Steeringandtravel
Movingthemachine
WARNING
Collisionhazard!
Alwaysmakesuretheareabehindthemachineisclearofallpersons,animals,andobstructionsBE-
FOREbackingup.
Failuretocomplycouldresultindeathorseriousinjury.
W0232A
WARNING
Lossofcontrolhazard!
Keephandsandfeetontheappropriatecontrolsatalltimestomaintaincontrolofthemachine.
Failuretocomplycouldresultindeathorseriousinjury.
W0237A
Pushboththeleft-handcontrollever(1)andtheright-
handcontrollever(2)forward,fromneutral,tomovethe
machineforward.Pullbothofthecontrolleversrearward,
fromneutral,tomovethemachineinthereversedirec-
tion.Movethecontrolleversforwardashortdistancefor
maximumpowerandslowspeed.Movethecontrollevers
completelyforwardformaximumspeed.
Movebothcontrolleverstotheneutralpositiontostop
movementofthemachine.
RAIL17SSL0037BA1
3-8
