CASE CONSTRUCTION Alpha Series - Electro Hydraulic Controls; Control Pattern Overview; Standard H Control Pattern

3-CONTROLSANDINSTRUMENTS
ELECTROHYDRAULICCONTROLS
Controlpatternoverview
StandardHcontrolpattern
93100555A11
Thechartbelowwillgiveadescriptionofthecontrolleverfunctions.Theleft-handcontrolleveris
representedbytheletter(A)andtheright-handcontrolleverbyletter(B).
(A)Left-handcontrollever
(1)Leftsidedriveforward.
(2)
Loaderarmlower.
(3)Leftsidedrivereverse.
(4)
Loaderarmraise.
(B)Right-handcontrollever
(5)Rightsidedriveforward.
(6)
Bucketdump.
(7)
Rightsidedrivereverse.
(8)Bucketrollback(curl).
NOTE:ThestandardHcontrolpatternusesbothleft-handandright-handcontrolleversforgrounddrivefunctions.
NOTICE:Donotoperatetheunituntilthehydraulicoilisatsufcientoperatingtemperature.
3-12
