3-CONTROLSANDINSTRUMENTS

Two-speedfunction

Two-SpeedFunction

Pressthetwo-speedbuttonontheleft-handcontrollever

oncetodownshiftfromsecondgeartorstgear.

Pressthebuttonagaintoshiftfromrstgeartosecond

gear.

NOTE:Thetwo-speedindicator

ontheleft-handcol-

umnilluminateswhenthetwo-speedfunctionisactive.

931002278A1

Function-enableconditions

Thetwo-speedfunctioncanbeactivatedONLYIFALL

ofthefollowingconditionsaremet.

•

Operatorisseatedproperly.

•

Therestraintbarisinthedownpositionwhiletheoper-

atorisintheseat.

•

Thehydraulicsystemisactivated.

•

Parkbrakeisnotset.

•

Ifapplicable,thekeyswitchisintheONposition.

3-28
