CASE CONSTRUCTION Alpha Series - General Specification

9-SPECIFICATIONS
Generalspecication
NOTE:AllspecicationsaregivenaccordingtoSAEstandardsorrecommendedpracticeswherethespecication
applies.
631093571
SMALLRADIALFRAMEWHEELUNITS(SR130,SR150)
ITEM
COMPONENTMEASUREMENT
A
OverallOperatingHeight(FullyRaised)3591mm(141.4in)
B
Heighttobuckethingepin(FullyRaised)2845mm(112in)
CT opofRollOverProtectiveStructure(ROPS)1919mm(75.5in)
DHighestLevelBucketHeight
2682mm(105.6in)
E
OverallLength(NoAttachment)2435mm(95.9in)
F
OverallLength(WithstandardBucket)3028.0mm(119.2in)
GDumpAngle(FullyRaised)40.2°
H
DumpHeight(MaximumReach)atfulldumpangle2246.0mm(88.4in)
J
DumpReach(FullyRaised)atfulldumpangle469mm(18.5in)
K
MaximumRollbackatGround26.1°
L
MaximumRollback(FullyRaised)95.2°
MWheelBase
941mm(37in)
P
GroundClearance(BellyPan)178mm(7in)
QAngleofDeparture22°
URearAxletoBumper
858mm(33.8in)
NOTE:Allmeasurementsarebasedonmachineswith10x16.5tiresanda1524.0mm(60.0in)Dirt&Foundry
(DF)bucket.
9-3
