7-MAINTENANCE

Cabdoor-Grease

Greasebothdoorhingesevery500hwithTUTELAMOLYGREASEGR-75.

1.Cleanthegreasettings(1)beforegreasing.

2.Openandclosethedoortoworkinthegrease.

RAIL13SSL0700BA1

7-66
