7-MAINTENANCE

EVERY500HOURS

Aircleanerelements

Bothaircleanerelementsshouldbechangedat500hoursofoperationoriftheairrestrictionindicatorisilluminated.

Aircleanerlterremoval

1.Opentheenginehoodandrearservicedoor.Engage

therearservicedoorlatchlocatednearthelowerhinge.

2.Pulltheyellowtabout,rotatethecovercounterclock-

wiseuntilthecapturnstoopen.Seeinstructionssym-

bolsanddecalonthecover.Pullthecapoffandclean

theinside.

931074941

3.Removetheprimarylter.

931074952

4.Removethesecondarylter.

931074963

7-53
