CASE CONSTRUCTION Alpha Series - Loader Arm Lock and Cab Tilt Procedure - Radial Lift Machines

2-SAFETYINFORMATION
Loaderarmlockandcabtiltprocedure-radialliftmachines
DANGER
Crushinghazard!
Donotenterorexittheoperator'scompartmentwhiletheloaderarmsareraisedorunsupported.Rest
theloaderarmsonthegroundorverifythatloaderarmisbeingsupportedbytheloaderarmstrutor
loaderarmlockpinbeforeenteringorexitingtheoperator'scompartment.
Failuretocomplywillresultindeathorseriousinjury.
D0168A
DANGER
Crushinghazard!
Theloaderarmisunsupportedduringsupportstrutremoval.Donotenterorexittheoperator'scom-
partmentwithanunsupportedloaderarm.Twopersonsarerequiredduringstorage.Oneperson
shouldremoveandstorethesupportstrutwhiletheoperatorremainsintheoperator'scompartment.
Failuretocomplywillresultindeathorseriousinjury.
D0021B
Raiseandlocktheloaderarmformachineservice
NOTE:Aninstructionaldecalontheinsideoftheright-
handloaderarm,justabovethesupportstrutisalsoavail-
able.Understandtheloaderarmlockprocedurebefore
continuing.
1.Sitintheoperator'sseat,fastentheseatbelt,pullthe
restraintbardown,andstarttheengine.
2.PresstheOPERATEbuttontoenablethehydraulics.
3.Removethebucketorattachmentfromthemounting
plate.
4.Parkthemachineonrmandlevelsurface.
5.Ifanassistantisnotavailable,turnofftheengineand
exitthemachine.
200929241
6.Removethesupportstrutpin(A)andletthesupport
strut(B)restontheliftcylinderbarrel(C).
93106848A2
2-18
