3-CONTROLSANDINSTRUMENTS
ISOcontrolpatternsteeringandtravel
Movingthemachine
WARNING
Lossofcontrolhazard!
Keephandsandfeetontheappropriatecontrolsatalltimestomaintaincontrolofthemachine.
Failuretocomplycouldresultindeathorseriousinjury.
W0237A
WARNING
Collisionhazard!
Alwaysmakesuretheareabehindthemachineisclearofallpersons,animals,andobstructionsBE-
FOREbackingup.
Failuretocomplycouldresultindeathorseriousinjury.
W0232A
RAIL17SSL0057FA1
Allsteeringandtravelcontrolsaredirectedwiththeleft-handcontrollever(1)only.Usethefaceofaclockforori-
entation.Themachinewillmoveinthedirectiontheleverismovedfromneutral,center.Releasetheleverandit
willdetenttoneutral.Althoughthemachinewillturnandcounter-turnsharply,itisbesttotravelthroughforwardor
reversegraduallywhenturning.
NOTE:Adjusttheseatlapbarformaximumstabilityofcontrolsandtoreduceoperatorfatigue.
Straightforwarddrive:
•
Pushthecontrolleverstraightforward(12:00position)andthemachinewillmoveforward.
Straightrearwarddrive:
•
Pullthecontrolleverstraightrearward(6:00position)andthemachinewillmoverearward.
3-19
