3-CONTROLSANDINSTRUMENTS

Cabairlouvers

Theairlouvers(1)arelocatedtothelowerrightandleftof

theoperatorandareadjustableforoperatorcomfort.Air

ow,directionandvolumecanbeadjusted.

Formaximumdefrosting,pointlouversindirectionofde-

sireddefrostarea.Airlouverscanrotate360°andtiltup

anddown,toachievethedirectionofoperatorsdesire.

9310074981
