CASE CONSTRUCTION Alpha Series - Window Removal and Cleaning

7-MAINTENANCE
Windowremovalandcleaning
WARNING
Avoidinjuryand/ormachinedamage!
Debrisonthewindowcanseverelyobstructtheoperator’svision.Toensurethattheoperatorhas
clearvisibilitythroughthewindows,alwayskeepthewindowsclean.
Failuretocomplycouldresultindeathorseriousinjury.
W1517A
NOTE:Machinesmaybeequippedwitheitherthepivotleverwindowstyleorthewindowlatchstyle.Followthe
procedurethatisapplicabletoyourmachine.
NOTICE:DONOTchangethewindowpositionwithoutproperlylockingthewindowlatch!ImproperuseWILLresult
inprematurewear.
NOTICE:Itissuggestedthatfornormalcleaning,awaterhoseorpowerwasheronlowpressurebeusedtoclear
theglassfromoutsideofthemachine.Donotdirectthestreamfromapowerwasherintothesealsorjointsofthe
window.Ifremovaloftheglassisnecessaryformaintenance,replacement,ormorethoroughcleaning,eachpane
canberemovedfrominsidethecab.
Windowlatchstyle
Removal
RAIL17SSL0039BA1
1
Sliderglass
5
Fixedupperglass
2Frame6Lowerseals
3Latch
7
Lowerglass
4Frame
Toolsrequired:Smallscrewdriver,atdrive,about178
–203mm(7–8in).
