7-MAINTENANCE

Finaldrivechaintankoil

Thenaldrivechaintankoilshouldbecheckedevery500hofoperation.

Finaldrivechaintankoilspecications:TUTELAAUTOSUPREME™ENGINEOILSAE10W-30

SR175andSV185modelsonly

1.Parkthemachineonarmlevelsurface.

2.Cleantheareaaroundthechaintankll/levelplug(1).

3.Removethechaintankll/levelplug(1).Theoilshould

beuptothebottomoftheinspectionorice.

RAPH12SSL0298BA1

4.Addoilifnecessary.

5.Replacethechaintankll/levelplug(1).

NOTE:UseLOCTITE®545™oranequivalentproducton

thethreadsoftheplug.

6.Repeatthisprocedurefortheotherside.

Capacity-eachside

SR175,SV1857.4l(7.9USqt)

7-59
