7-MAINTENANCE

SR200modelonly

1.Parkthemachineonarmlevelsurface.

2.Cleantheareaaroundthechaintankll/levelplug(1).

3.Removethechaintankll/levelplug(1).Theoilshould

beuptothebottomoftheinspectionorice.

RAPH12SSL0298BA2

4.Addoilifnecessary.

5.Replacethechaintankll/levelplug(1).

NOTE:UseLOCTITE®545™oranequivalentproducton

thethreadsoftheplug.

6.Repeatthisprocedurefortheotherside.

Capacity-eachside

SR20026.0l(27.5USqt)

7-60
