CASE CONSTRUCTION Alpha Series - Lubrication and Maintenance Access

7-MAINTENANCE
Lubricationandmaintenanceaccess
1.Opentheenginecompartmenthoodbypivotingup-
ward.
NOTE:Thisstylehoodmaybelockedwithapadlock.
2.Liftuponthelatchtabtoopentherearservicedoor.
931068581
Theopenenginehoodandrearaccessdoor(1)willallow
theoperatorortechnicianto:
•
Checktheengineoil.
•
Accessengineoilll.
•
Addfuel.
•
Checkradiatorandhydraulicoilcoolers(ll,drainand
cleandebris).
•
WARNING
Hotliquidunderpressure!
Scaldingcanresultfromfastremovalofthera-
diatorcap.Checkandservicetheenginecool-
ingsystemaccordingtothemaintenancein-
structionsinthismanual.
Failuretocomplycouldresultindeathorseri-
ousinjury.
W0163A
Checkandcleanthecoolantreservoir.
•
Servicebothfuellters(in-lineandspinonelementwa-
terseparator)drainwaterfromspinonlterelement
canister
•
Servicethehydrauliclter.
•
Servicetheairlters.
•
Accesshydraulicoilll.
•
Checkthedrivebelts.
•
Checkthealternator.
631074882
Alwayslocktherearaccessdooropenwhenservicingor
monitoringcomponents,asshown(2).
931068783
7-16
