CASE CONSTRUCTION Alpha Series - Final Drive Chain Tank Oil

7-MAINTENANCE
Finaldrivechaintankoil
Changetheoilinthechaintanksevery1000hofoperation.
Finaldrivechaintankoilspecication:TUTELAAUTOSUPREME™ENGINEOILSAE10W-30
SR175andSV185modelsonly
1.Parkthemachineonrmlevelsurface.
2.Cleantheareaaroundthechaintankdrainplugs(not
shown),locatedonthebottomofthedrivechaintank,
neartherearofthedrivechaintank,oneoneachside.
3.Cleantheareaaroundthechaintankll/levelplug(1).
4.Placeasuitablecontainerunderthechaintankdrain
plugandslowlyremovethedrainplug.
NOTE:Useajackandraisethefrontofthemachineslightly
forbetterdraining.
5.Removethechaintankll/levelplug(1).
6.Aftertheoilhasbeencompletelydrained,replacethe
chaintankdrainplug.
7.Fillthetankwithnewoilandreplacethechaintank
ll/levelplug(1).
NOTE:UseLOCTITE®545™oranequivalentproducton
thethreadsoftheplugs.
8.Repeatthisprocedurefortheotherside.
RAPH12SSL0298BA1
NOTE:Thechaintankmaybecleanedwithasolventbasedcleanerbyremovingtheinspectioncover(2)oneach
side,aftertheoilhasbeenremoved.Allowthetanktodrythoroughlybeforellingwithoil.
Capacity-eachside
SR175,SV1857.4l(7.9USqt)
7-72
