CASE CONSTRUCTION Alpha Series - Every 50 Hours; Cab Intake Filter

7-MAINTENANCE
EVERY50HOURS
Cabintakelter
Ifthemachineisequippedwithacabheaterorairconditioning,thecabintakeltershouldbeinspectedasshown.
Thecabintakelter(1)islocatedinsidethecabbehindtheseatbelowtherearwindow.
NOTE:Theserviceintervalforthecabintakelterisdependentontheamountofuseandtheoperatingconditions.
Itisrecommendedtocheckmoreoftenifworkinginextremeenvironmentalconditions.
1.Opentheaccesscoverusingknobs(2).Replacethe
cabintakelterifitisdamaged,torn,orifitisclogged
withdebrisanddirt.
931068831
2.Removethecabintakelter(3).
NOTICE:Maintainthelterinahorizontalorientationwhen
removingfromtheairbox.Thiswillpreventdustanddebris
frombeingaccidentlydumpedinthecab.
931068842
3.Cleanthecabintakeltercompartmentofdirtandde-
bris.Therubbergasketontheltermustsealproperly
withthecompartmentlterange.
4.Replacetheneworcleanedcomponentsinthereverse
order.
93107489A3
NOTICE:Makesuretogetagoodsealbetweenthelterandthehousing.
