3-CONTROLSANDINSTRUMENTS
Liftarmandbucketcontrols
Handcontrols
93109347C1
Liftarmraiseandlowercontrol.
•
Theleft-handcontrollever(1)controlstheliftarm.The
liftarmwillraisebypivotingthehandle“UP”totheout-
sideofthecab.Pivotingthehandle“DOWN”tothein-
sideofthecabwilllowertheliftarm.
•
Theliftarmspoolisequippedwithadetented“FLOAT”
circuitiftheoperatorwantstheliftarmtooatover
changinggroundcontour.T oputthevalvein“FLOAT”
position,pivotthelefthandle“DOWN”untilaslight
“jump”isfelt.Inthisposition,thehandleislockedin
oatanddoesnotreturntotheneutralpositionunas-
sisted,butwilldosowhenlightpressureisappliedto
thehandletopivotit“UP”.
RAIL13SSL0957AB2
Bucketdumpandcurlcontrol.
•
Therighthandcontrollever(2)controlsthebucket.The
bucketwilldumpbypivotingthehandle“UP”totheout-
sideofthecab.Pivotingthehandle“DOWN”tothein-
sideofthecabandthebucketwillrollback(curl).
NOTE:Thereisnodetentoroatpositiononthebucket
dumporcurlspools.
RAIL13SSL0956AB3
