CASE CONSTRUCTION Alpha Series - Roll over Protective Structure (ROPS) Mechanism and Hardware Check

7-MAINTENANCE
RollOverProtectiveStructure(ROPS)mechanismandhardware
check
WARNING
Roll-overhazard!
Securelyfastentheseatbelt.YourmachineisequippedwithaRoll-OverProtectiveStructure(ROPS)
cab,ROPScanopy,orROPSframeforyourprotection.Theseatbeltcanhelpensureyoursafetyifit
isproperlyusedandmaintained.Neverwearaseatbeltlooselyorwithslackinthebeltsystem.
Failuretocomplycouldresultindeathorseriousinjury.
W0143A
ChecktheROPScabtolowermainframehardwarefor
propertorque.
1.ChecktheROPShardwareatthebackofthemachine
thatareusedtosecurethecab.T orquethehardware
to170N·m(125.4lbft).
9310016331
2.ChecktheROPSfrontpivotbolts.Torquethesebolts
to42N·m(31.0lbft).
RAIL14SSL0469BA2
