CASE CONSTRUCTION Alpha Series - Battery Disconnect Switch; Fire Extinguisher

7-MAINTENANCE
Batterydisconnectswitch
Usethebatterydisconnectswitchtheenableordisable
electricalpowerfromthemachinebatteriestothe
electricalcomponents.
1.Opentheenginehoodandrearservicedoor.Engage
therearservicedoorlatch(1)locatednearthelower
hinge.
2.Turnthebatterydisconnectswitch(2)clockwisefor
theONposition(shown)andcounterclockwiseforthe
OFFposition.
NOTICE:Somemachineserviceproceduresrequirean
actualterminaldisconnectofthebatteries.Donotusethe
batterydisconnectswitchforthosetypesofprocedures,
suchasweldingonthemachine.
631074881
RAIL17SSL0040BA2
Fireextinguisher
Itisrecommendedthatyouhaveareextinguisheron
yourmachine.Seeyourdealerforthetypeandmounting
information.
NOTICE:Usethereextinguishermountingkitprovided
byyourdealer.DONOTmakeanymodicationstothe
ROPSorFOPSstructure.
NOTICE:Forreextinguisherinspectionandservice,
seemanufacturesrecommendation,locatedonreex-
tinguisher.
7-8
