CASE CONSTRUCTION Alpha Series - H Control Pattern Steering and Travel; Hand Controls

3-CONTROLSANDINSTRUMENTS
Hcontrolpatternsteeringandtravel
Handcontrols
WARNING
Collisionhazard!
Alwaysmakesuretheareabehindthemachineisclearofallpersons,animals,andobstructionsBE-
FOREbackingup.
Failuretocomplycouldresultindeathorseriousinjury.
W0232A
WARNING
Lossofcontrolhazard!
Keephandsandfeetontheappropriatecontrolsatalltimestomaintaincontrolofthemachine.
Failuretocomplycouldresultindeathorseriousinjury.
W0237A
Left-handcontrollever
Bymovingtheleft-handcontrolleverforwardfromneutral,
theleft-handsidetireswillrotateforward.Whentheleft-
handcontrolleverismovedrearwardfromneutral,the
left-handsidetireswillrotateinreverse.
RAIL17SSL0037BA1
Right-handcontrollever
Bymovingtheright-handcontrolleverforwardfromneu-
tral,theright-handsidetireswillmoveforward.Whenthe
right-handcontrolleverismovedrearwardfromneutral,
theright-handsidetireswillmoveinreverse.
RAIL17SSL0037BA2
3-14
