CASE CONSTRUCTION Alpha Series - Advanced Instrument Cluster (AIC)

3-CONTROLSANDINSTRUMENTS
AdvancedInstrumentCluster(AIC)
TheAdvancedInstrumentCluster(AIC)isontheright-
handcabpost.
Onceintheseat,thealarmsoundsandselectedlamps
illuminatebriey.Monitortheselampsonadailybasis
toconrmthattheywillfunctionintheeventofasystem
alarm.Thefuelgaugeandhourmeterwillremainillumi-
natedforoperatormonitoring.
Whenstarted,themachinewillbeinparkwiththepark
brake(1)lampilluminated.Theparkbrakebuttonison
theright-handcontrollever.
Theoperatormustbeintheseatwithseatbeltfastened
andtherestraintbarlowered.Afterthemachinestarts,
theoperatormustpushtheOPERATEbutton(2)toacti-
vatetheloaderarmsandgrounddrive.
Asemi-hidden“Setup”menuallowstheusertoview,se-
lect,changeandcustomizeanumberofmachinesettings.
AsecuritycodemaybeenteredintotheInstrumentClus-
ter.Oncethesecuritycodehasbeenentered,eachuser
willhavetoenterthecodebeforethemachinewillstart.
Contactyourdealerfordetailedinformationonthe“Setup”
menuandsecurityfeatureactivation.
NOTE:Faultcodedenitionsarelocatedinthetrou-
bleshootingsection.Theupdatedfaultcodeisvisibleto
theoperatoronthedisplayontheright-handcolumn.
NOTICE:Lowhydraulicchargepressurewillcauseen-
gagementoftheparkbrake.WithanElectro-Hydraulic
(EH)controlunit,theparkbrake(1)lampwillashandan
audiblealarmwillsound,ifthisconditionexists.
