CASE CONSTRUCTION Alpha Series - Initial 100 Hours; Final Drive Oil (Track Models)

7-MAINTENANCE
INITIAL100HOURS
Finaldriveoil(trackmodels)
Changethenaltrackdrivegearoilaftertheinitial100hofoperationandthenevery500hofoperation.
Finaltrackdrivegearoilspecication–TUTELAHYPOIDEEPGEARLUBESAE80W-90
Tochangeoil
1.Positionthenaldrivehubsothatoneofthedrainplugs
(2)isinthe6:00positionasshown.
2.Removedrainplug(2)andletoildraincompletelybe-
forereplacingthedrainplug.
RAIL15SSL0358AA1
3.Rotatethehubsoonedrainplug(1)isatthe12:00
positionandtheotherplug(2)isat3:00or9:00position
asshown.
4.Usingafunnel,llthetrackdrivehubuntiloilstartsto
owfrom(2)thatisat3:00or9:00position.
5.Insertbothplugs(1)and(2)andwipeanyexcessor
spilledoilandrepeatthisprocedureontheotherside
ofthemachine.
RAIL15SSL0359AA2
Capacity-eachside1.0L(1.06USqt)+/-0.1L(0.1USqt)
SpecicationsTUTELAHYPOIDEEPGEARLUBESAE80W-90
Tocheckoillevel
1.T ocheckthenaldriveoillevel,rotatethehubsoone
drainplug(1)isatthe12:00positionandtheotherplug
(2)isat3:00or9:00positionasshown.
2.Removethedrainplug(2).Iftheoillevelisattheproper
level,theoilshouldbeevenwiththebottomofthedrain
plug.
3.Iftheoilislow,removethetopplug(1)andaddoiluntil
itstartstoowoutof(2).
RAIL15SSL0359AA3
7-46
