7-MAINTENANCE
SR130,SR150,SR220,SR250,SV250,andSV300modelsonly
1.Parkthemachineonrmlevelsurface.
NOTE:ForModelsSR130andSR150only:Raisethemachineenoughtoremovethewheelsandblockthemachine
withsupportblockstosecurethemachineinalevelposition.Removethefrontrightwheelandtherearleftwheel
fromthemachinetoaccessthechaintankll/levelplug(1).
2.Cleantheareaaroundthechaintankll/levelplug(1).
3.Removethechaintankll/levelplug(1).Theoilshould
beuptothebottomoftheinspectionorice.
RCPH11SSL006AAD3
4.Addoilifnecessary.
5.Replacethechaintankll/levelplug(1).
NOTE:UseLOCTITE®545™oranequivalentproducton
thethreadsoftheplug.
6.Repeatthisprocedurefortheotherside.
Capacity-eachside
SR130,SR1506.25l(6.6USqt)
SR220,SR250,SV250,SV300,22.2l(23.5USqt)
7-61
