7-MAINTENANCE

Sliderglass

1.Verifythatthesliderglassisshutandlatched.

RAIL17SSL0039BA2

2.Slipthescrewdriverdownintothealuminumtrackfrom

theback,andslideforwardunderneaththerearinner

rigidPVCsliderchannel.

RAIL17SSL0348BA3

3.Pryupwarduntilyouareabletograbholdoftheendof

thePVCchannel.

4.LiftthePVCchannelupandoutofthetrack.Pullrear-

warduntilitslidesfreefromunderneaththesliderglass.

5.Unlatchandmovethesliderglassrearwarduntilit

clearsthefrontPVCchannel.

RAIL17SSL0038BA4

7-80
