3-CONTROLSANDINSTRUMENTS
(12)
Loaderlockoutswitch
Ifequipped,pushtodisableloadercontrol
whileroadingtheunit.Thebucketand
loaderarmwillbelockedintheposition
theyareinwhentheloaderlockoutswitchis
pressedtotheONposition.Thisprevents
theoperatorfrominadvertentlylowering
orraisingtheloaderarmorbucketwhile
drivingthemachineonroads.
NOTE:Amechanicalmachinewiththe
loaderlockoutactivatedwillresultinanac-
tivefaultcode4952alongwithanamber
lampandbuzzer.Theauxiliaryoverridebut-
ton(lowerleft)ontheinstrumentclustercan
bepressedtoclearthedisplayandsilence
thebuzzer.Theamberlampwillremain
illuminated.
(13)
Windshieldwiperswitch
Ifequipped,thisthreepositionswitchturns
thewiperON/OFFandoperatesthewasher
uidspray.
(14)Blank(empty)
Thislocationisleftopenforanyoptionsyou
mayaddinthefuture.
(15)
12VPowerport
Supplies12Vofpowerforaccessories.
RAPH12SSL0031DA3
