5-TRANSPORTOPERATIONS

SR130andSR150only

Frontslingrequirements:

•

Twosyntheticslings3.7m(12.0ft)inlength.

•

Eachslingmusthavearatedliftingcapacityofequalto

orgreaterthan0.706xGrossVehicleWeight(GVW).

Rearslingrequirements:

•

Twochainsapproximately2.5m(8.1ft)inlength.

Someadjustmentmayberequiredforalevellift.

•

Eachchainmusthavearatedliftingcapacityofequalto

orgreaterthan0.550xGrossVehicleWeight(GVW).

RAIL14SSL0403BA6

NOTE:Foraclearviewofthemachine’sliftingpointsand

theslingroutingtheloaderarmisnotshown.Donot

removetheloaderarms.

Ateachofthemachine’sliftingpointswillbealiftingpoint

decal

RAIL14SSL0405BA7

5-4
