SR130,SR150,SR220,SR250,SV250,andSV300modelsonly
1.Parkthemachineonrmlevelsurface.
NOTE:FormodelsSR130andSR150only:Raisethemachineenoughtoremovethewheelsandblockthemachine
withsupportblockstosecurethemachineinalevelposition.Removethefrontrightwheelandtherearleftwheel
fromthemachinetoaccessthechaintankll/levelplug(1).
2.Cleantheareaaroundthechaintankdrainplugs(not
shown),locatedonthebottomofthedrivechaintank,
neartherearofthedrivechaintank,oneoneachside.
3.Cleantheareaaroundthechaintankll/levelplug(1).
4.Placeasuitablecontainerunderthechaintankand
slowlyremovethetankdrainplug.
NOTE:Useajackandraisethefrontofthemachineslightly
forbetterdraining.
5.Removethechaintankll/levelplug(1).
6.Aftertheoilhasbeencompletelydrained,replacethe
chaintankdrainplug.
7.Fillthetankwithnewoilandreplacethechaintank
ll/levelplug(1).
NOTE:UseLOCTITE®545™oranequivalentproducton
thethreadsoftheplugs.
8.Repeatthisprocedurefortheotherside.
RCPH11SSL006AAD3
NOTE:Thechaintankmaybecleanedwithasolventbasedcleanerbyremovingtheinspectioncover(2)oneach
side,aftertheoilhasbeenremoved.Allowthetanktodrythoroughlybeforellingwithoil.
Capacity-eachside
SR130,SR1506.25l(6.6USqt)
SR220,SR250,SV250,SV300,22.2l(23.5USqt)
