8-TROUBLESHOOTING
Code
FunctionDescription
Code
FunctionDescription
5215
GroundDriveShortCircuittoPower
5507
AuxControlFunctionOpenCircuit
5217
GroundDriveJoystickoutofrange
5508
AuxControlFunctionShortCircuitto
Power
5000to5999(electro-hydraulicsystemerrors)–continued
Code
FunctionDescription
Code
FunctionDescription
5511
BoomRaise/LowerSensorImplausibleState
5603
AuxControlFunctionOpenCircuit
5512
BucketRollback/
Dump
SensorImplausibleState
5701
PatternSelect(ISO/H)OpenCircuit
5513
AuxControl
Function
SensorImplausibleState
5703
PatternSelect(ISO/H)ShortCircuitto
Power
5601
AuxControl
Function
ShortCircuittoPower
5709
PatternSelect(ISO/H)SwitchTimeout
5602
AuxControl
Function
ShortCircuittoGround
5911
PatternSelect(ISO/H)SwitchTimeout
9000to9999(internaldisplayerrors)
Code
FunctionDescription
Code
FunctionDescription
9151
CANBus
Communication
NonmessageCAN-Bus
9403MemoryError
InstrumentCluster
MemoryError
9156HydraulicsEnable
ButtonStateError
9404MemoryError
InstrumentCluster
MemoryError
9157
AuxOverrideCANmessageError
9405
CANCommunicationLossof
Communication
fromUCM
9158
PatternSelect
(ISO/H)
ShortCircuittoGround
9406
CANCommunicationLossof
Communication
fromUCM
9159
PatternSelect
(ISO/H)
ShortCircuittoGround
9407MemoryError
InstrumentCluster
MemoryError
9160
PatternSelect
(ISO/H)
ShortCircuittoPower
9408MemoryError
InstrumentCluster
MemoryError
9161
PatternSelect
(ISO/H)
ShortCircuittoPower
