2-SAFETYINFORMATION

Seatrestraintbar

Therestraintbarmustbedownintheoperatingposition

beforestarting.

Seatrestraintbarintheraisedposition.

931093332

Seatrestraintbarintheoperatingposition.

931093073

2-13
