3-CONTROLSANDINSTRUMENTS

Gradualturn-powertobothsidesinthesamedirection

•

Tomakeagradualforwardturnleft:fromneutral,push

theleft-handcontrolleverforwardandslightlytoward

the11:00position.

•

Tomakeagradualforwardturnright:fromneutral,push

theleft-handcontrolleverforwardandslightlytoward

the1:00position.

BS06G0373

3-21
