1-GENERALINFORMATION

SCR(SelectiveCatalyticReduction)serialnumber

ThenumberisstampedontopoftheSCRblock.

1.CenterDOC(DieselOxidationCatalyst)serial:

2.SCRserial:

SMIL19CEX1982AA7

CabprotectionROPS(RollOverProtectiveStructure)

ComplieswithISO12117-2.

Productidenticationnumber:

SMIL17CEX5115AA8

CabprotectionFOPS(FallingObjectsProtectiveStructure)

ComplieswithISO10262level1(cabroof).

ComplieswithISO10262level2(withoptionalbolt-ontop

guard).

Productidenticationnumber:

SMIL17CEX5116AA9
