9-ACCESSORIES
9.TurntheMAINSWITCH(3)toONposition.
10.TurntheARMPOSITIONswitch(5)toBOTTOMpo-
sitiontolowerthearm.
11.TurntheCTWTPOSITIONswitch(4)toRAISEposi-
tionuntiltheliftingcylindersarefullyextended.
SMIL20CEX1358BA15
12.Getontothecab,andturntheenginespeedthrottle
tolowidleposition.Waitforthegreencoolingdown
icontoappear.
13.Stoptheengineandremovethestarterkey.
14.Stepdowntotheground,andreachtheliftingbrack-
etsofthecounterweight.
15.Removetheclips(6).
16.Removethepins(7).
17.T akethewireropes(8)intothebrackets.
18.Fixthewireropestothebracketsbymeansofthe
pins(7),andlockthepinsbymeansoftheclips(6).
19.Getontothecab,starttheengine,andmakesure
thatthegatelockleverisincentralposition.
20.Settheenginespeed4-5stepsabovelowidle.
SMIL20CEX1354BA16
