9-ACCESSORIES

21.Reachtherearright-handcompartment.

22.TurntheARMPOSITIONswitch(5)toTOPposition

toraisethearmuntilitstandsverticalintoitscom-

partmentontheupperframe.Checkthatthecoun-

terweightisproperlyalignedtotheupperframe.

SMIL20CEX1359BA17

23.TurntheCTWTPOSITIONswitch(4)toLOWER

positiontolowerthecounterweighttoitsmounting

frame.Makesurethatthecounterweightisproperly

engagedtothemountingframe,andthatitisaligned

totheupperframe,tothedoors,andtotheengine

hood.Makesurethattheholesofthemountingbolts

ontheupperframeandonthecounterweightare

aligned.

SMIL20CEX1360BA18

9-56
