Cellwatch Frontier System Installation & User Manual
Section I – Installation Guide-17
Enhanced Measurement
Characteristics (Requires Activation)
Range Resolution Accuracy
Voltage 0 to 80V 2mV 0.1% +/- 5mV
Ohmic Value 0 to 1mΩ 1µΩ 2% +/- 8µΩ
1 to 65mΩ 1µΩ 1.5%
Cell Temperature (requires DCM5T)
2 to 80°C 0.01°C +/- 1°C
Ripple Voltage across 4 channels
(40Hz – 1KHz)
Fiber Optic Specification
Optic Cable Acrylic
Sheathing Fluorine containing polymer
Core Diameter 1.0 mm
Outside Diameter 2.2 mm
Wavelength 400-700 nm
Communication Rate 9600 baud
Fiber Optic Range Min: 150 mm (6 in.) to Max: 50 m (150 ft.)
Mechanical
Dimensions 4.2 in. x 3.1 in. x 0.9 in. (107 mm x 80 mm x 23 mm)
Mounting Pads 3M™ Dual Lock™
Base Plate with Mounting Holes Optional
Base Plate with DIN Rail Mount Optional
Enclosure Material ABS
Lead Length 36-72 in.
DCM6-L
The DCM6-L is designed for use with 2-volt jars. It can operate up to a maximum power supply voltage
of 12 volts between the white and brown wires. Unlike previous DCMs, the white and blue must be at
the same DC voltage (connected to the same cell terminal post). Note the DCM6-L will not power up,
flash the LEDs and play its startup song until the white, blue and brown wires are connected.
The DCM6-L cannot measure Ripple Voltage. A DCM6-R will be required to measure Ripple Voltage on a
system utilizing DCM6-L units.
The DCM6-L has a lower quiescent current than previous DCMs and so must not be mixed on the same
string of cells, it can however operate on the same fiber optic loop as previous DCM models.
