Cellwatch Frontier System Installation & User Manual
Section I – Installation Guide-18
DCM6-L Specifications
Description DCM6-L
Environment
Operating temperature 0 to 60ºC
Relative Humidity 5 - 85% non-condensing
Maximum Altitude 3,000 meters (10,000ft)
Power supply full functionality 4 - 12 Volts DC
Power supply voltage &
temperature
3 - 12 Volts DC
Protection
Transient suppression 600W
Short circuit protection Internal 4-amp fuse
Reverse polarity protection Any combination
Insulation resistance 1000 MΩs >1Kv
Operating current
Quiescent current 12mA
Sleep current after 25 hours <2ma
During ohmic testing 1.5 amps
Standard Measurement
Characteristics
Range Resolution Accuracy
Voltage 0 to 12 volts 15 mV 0.1% +/-15mv
Ohmic Value 0 to 5mΩ 6.3µΩ 2% +/- 15 µΩ
Enhanced Measurement Characteristics Requires Activation
Voltage 0 to 12 volts 2mV 0.1% +/-5mv
Ohmic Value 0 - 5mΩ 1µΩ 2% +/- 8 µΩ
Temperature -ve post (optional) 2 to 80ºC 0.01ºC +/- 1ºC
Mechanical
Fiber optic range Min: 150mm (6”) to Max: 50meters (150 ft)
Dimensions 4.2" x 3.1" x 0.9" 107mm x 80mm x 23mm
Mounting pads 3M Dual Lock™
Base plate with mounting holes Optional
Base plate with DIN rail mount Optional
Enclosure Material ABS
Wire lead length 40 - 72 inches
DCM6-H
The DCM6-H is designed to work from 12- 80 volts. It will work on 4, 6, 8, 12, 16-volt containers
provided the total voltage between the white and brown wires is >12 volts. Use the DCM6-L on 2-volt
cells. The container voltage restriction is the only installation difference between the DCM6-H and the
DCM5.
