98 Functional Description CG Drives & Automation, 01-5326-01r5
Communication information
Motor Frequency [222]
Set the nominal motor frequency.
Communication information
Motor Power [223]
Set the nominal motor power. If parallel motors, set the
value as sum of motors power. The nominal motorpower
must be within the range of 1 - 150% of the AC drives
nominal power.
Communication information
P
NOM
is the nominal AC drive power.
Motor Current [224]
Set the nominal motor current. If parallel motors, set the
value as sum of motors current.
Communication information
Modbus Instance no/DeviceNet no: 43041
Profibus slot/index 168/200
EtherCAT and CANopen index (hex) 4be1
Profinet IO index 19425
Fieldbus format Long, 1=0.1 V
Modbus format EInt
222 Motor Freq
Default: 50 Hz
Range: 20.0 - 300.0 Hz
Resolution 0.1 Hz
Modbus Instance no/DeviceNet no: 43060 = 0.1 43042 = 1
Profibus slot/index 168/219 168/201
EtherCAT and CANopen index
(hex)
4bf4 4be2
Profinet IO index 19444 19426
Fieldbus format Long, 1=0.1 Hz Long, 1=1 Hz
Modbus format EInt EInt
223 Motor Power
Default: (P
NOM
) kW, AC drive
Range: 1-150 % x P
NOM
Resolution 3 significant digits
NOTE: The Motor Power value will always be stored
as a 3 digit value in W up to 999 W and in kW for all
higher powers.
Modbus Instance no/DeviceNet no: 43043
Profibus slot/index 168/202
EtherCAT and CANopen index (hex) 4be3
Profinet IO index 19427
Fieldbus format Long, 1=1 W
Modbus format EInt
224 Motor Curr
Default: (I
MOT
) A (see Note 2 page 97)
Range: 25 - 150% x I
NOM
A
Modbus Instance no/DeviceNet no: 43044
Profibus slot/index 168/203
EtherCAT and CANopen index (hex) 4be4
Profinet IO index 19428
Fieldbus format Long, 1=0.1 A
Modbus format EInt
NOTE: The default settings are for a standard 4-pole
motor according to the nominal power of the AC
drive.
WARNING!
Do not connect motors with less than 25%
of the nominal power of the AC drive. This
may disrupt the control of the motor.
