CG Emotron VFX Series User Manual

CG Drives & Automation,01-5326-01r5 Functional Description 113
Motor I
2
t Trip Type [25B]
Select the preferred way to react to a Motor I
2
t trip.
Communication information
PT100 [25C]
Delay time starts counting when the fault is gone. When the
time delay has elapsed, the alarm will be reset if the function
is active.
Communication information
PT100 Trip Type [25D]
Delay time starts counting when the fault is gone. When the
time delay has elapsed, the alarm will be reset if the function
is active.
Communication information
PTC [25E]
Delay time starts counting when the fault is gone. When the
time delay has elapsed, the alarm will be reset if the function
is active.
Communication information
PTC Trip Type [25F]
Select the preferred way to react to a PTC trip.
Communication information
External Trip [25G]
Delay time starts counting when the fault is gone. When the
time delay has elapsed, the alarm will be reset if the function
is active.
Communication information
25B Motor I
2
t TT
Default: Trip
Trip 0 The motor will coast
Deceleration 1 The motor will decelerate
Modbus Instance no/DeviceNet no: 43074
Profibus slot/index 168/233
EtherCAT and CANopen index (hex) 4c02
Profinet IO index 19458
Fieldbus format UInt
Modbus format UInt
25C PT100
Default: Off
Off 0 Off
1–3600 1–3600 1–3600 s
Modbus Instance no/DeviceNet no: 43078
Profibus slot/index 168/237
EtherCAT and CANopen index (hex) 4c06
Profinet IO index 19462
Fieldbus format Long, 1=1 s
Modbus format EInt
25D PT100 TT
Default: Trip
Selection: Same as menu [25B]
Modbus Instance no/DeviceNet no: 43079
Profibus slot/index 168/238
EtherCAT and CANopen index (hex) 4c07
Profinet IO index 19463
Fieldbus format Uint
Modbus format UInt
25E PTC
Default: Off
Off 0 Off
1–3600 1–3600 1–3600 s
Modbus Instance no/DeviceNet no: 43084
Profibus slot/index 168/243
EtherCAT and CANopen index (hex) 4c0c
Profinet IO index 19468
Fieldbus format Long, 1=1 s
Modbus format EInt
25F PTC TT
Default: Trip
Selection: Same as menu [25B]
Modbus Instance no/DeviceNet no: 43085
Profibus slot/index 168/244
EtherCAT and CANopen index (hex) 4c0d
Profinet IO index 19469
Fieldbus format UInt
Modbus format UInt
25G Ext Trip
Default: Off
Off 0 Off
1–3600 1–3600 1–3600 s
Modbus Instance no/DeviceNet no: 43080
Profibus slot/index 168/239
EtherCAT and CANopen index (hex) 4c08
Profinet IO index 19464
Fieldbus format Long, 1=1 s
Modbus format EInt
