CG Emotron VFX Series User Manual

114 Functional Description CG Drives & Automation, 01-5326-01r5
External Trip Type [25H]
Select the preferred way to react to an alarm trip.
Communication information
Communication Error [25I]
Delay time starts counting when the fault is gone. When the
time delay has elapsed, the alarm will be reset if the function
is active.
Communication information
Communication Error Trip Type
[25J]
Select the preferred way to react to a communication trip.
Communication information
Min Alarm [25K]
Delay time starts counting when the fault is gone. When the
time delay has elapsed, the alarm will be reset if the function
is active.
Communication information
Min Alarm Trip Type [25L]
Select the preferred way to react to a min alarm trip.
Communication information
Max Alarm [25M]
Delay time starts counting when the fault is gone. When the
time delay has elapsed, the alarm will be reset if the function
is active.
Communication information
25H Ext Trip TT
Default: Trip
Selection: Same as menu [25B]
Modbus Instance no/DeviceNet no: 43081
Profibus slot/index 168/240
EtherCAT and CANopen index (hex) 4c09
Profinet IO index 19465
Fieldbus format UInt
Modbus format UInt
25I Com Error
Default: Off
Off 0 Off
1–3600 1–3600 1–3600 s
Modbus Instance no/DeviceNet no: 43089
Profibus slot/index 168/248
EtherCAT and CANopen index (hex) 4c11
Profinet IO index 19473
Fieldbus format Long, 1=1 s
Modbus format EInt
25J Com Error TT
Default: Trip
Selection: Same as menu [25B]
Modbus Instance no/DeviceNet no: 43090
Profibus slot/index 168/249
EtherCAT and CANopen index (hex) 4c12
Profinet IO index 19474
Fieldbus format UInt
Modbus format UInt
25K Min Alarm
Default: Off
Off 0 Off
1–3600 1–3600 1–3600 s
Modbus Instance no/DeviceNet no: 43091
Profibus slot/index 168/250
EtherCAT and CANopen index (hex) 4c13
Profinet IO index 19475
Fieldbus format Long, 1=1 s
Modbus format EInt
25L Min Alarm TT
Default: Trip
Selection: Same as menu [25B]
Modbus Instance no/DeviceNet no: 43092
Profibus slot/index 168/251
EtherCAT and CANopen index (hex) 4c14
Profinet IO index 19476
Fieldbus format UInt
Modbus format UInt
25M Max Alarm
Default: Off
Off 0 Off
1–3600 1–3600 1–3600 s
Modbus Instance no/DeviceNet no: 43093
Profibus slot/index 168/252
EtherCAT and CANopen index (hex) 4c15
Profinet IO index 19477
Fieldbus format Long, 1=1 s
Modbus format EInt
