CG Drives & Automation,01-5326-01r5 Functional Description 115
Max Alarm Trip Type [25N]
Select the preferred way to react to a max alarm trip.
Communication information
Over current F [25O]
Delay time starts counting when the fault is gone. When the
time delay has elapsed, the alarm will be reset if the function
is active.
Communication information
Pump [25P]
Delay time starts counting when the fault is gone. When the
time delay has elapsed, the alarm will be reset if the function
is active.
Communication information
Over Speed [25Q]
Delay time starts counting when the fault is gone. When the
time delay has elapsed, the alarm will be reset if the function
is active.
Communication information
External Motor Temperature [25R]
Delay time starts counting when the fault disappears. When
the time delay has elapsed, the alarm will be reset if the
function is active.
Communication information
External Motor Trip Type [25S]
Select the preferred way to react to an alarm trip.
Communication information
25N Max Alarm TT
Default: Trip
Selection: Same as menu [25B]
Modbus Instance no/DeviceNet no: 43094
Profibus slot/index 168/253
EtherCAT and CANopen index (hex) 4c16
Profinet IO index 19478
Fieldbus format UInt
Modbus format UInt
25O Over curr F
Default: Off
Off 0 Off
1–3600 1–3600 1–3600 s
Modbus Instance no/DeviceNet no: 43082
Profibus slot/index 168/241
EtherCAT and CANopen index (hex) 4c0a
Profinet IO index 19466
Fieldbus format Long, 1=1 s
Modbus format EInt
25P Pump
Default: Off
Off 0 Off
1–3600 1–3600 1–3600 s
Modbus Instance no/DeviceNet no: 43095
Profibus slot/index 168/254
EtherCAT and CANopen index (hex) 4c17
Profinet IO index 19479
Fieldbus format Long, 1=1 s
Modbus format EInt
25Q Over speed
Default: Off
Off 0 Off
1–3600 1–3600 1–3600 s
Modbus Instance no/DeviceNet no: 43096
Profibus slot/index 169/0
EtherCAT and CANopen index (hex) 4c18
Profinet IO index 19480
Fieldbus format Long, 1=1 s
Modbus format EInt
25R Ext Mot Temp
Default: Off
Off 0 Off
1–3600 1–3600 1–3600 s
Modbus Instance no/DeviceNet no: 43097
Profibus slot/index 168/239
EtherCAT and CANopen index (hex) 4c19
Profinet IO index 19481
Fieldbus format Long, 1=1 s
Modbus format EInt
25S Ext Mot TT
Default: Trip
Selection: Same as menu [25B]
Modbus Instance no/DeviceNet no: 43098
Profibus slot/index 168/240
EtherCAT and CANopen index (hex) 4c1a
Profinet IO index 19482
Fieldbus format UInt
Modbus format UInt
