CG Emotron VFX Series User Manual

116 Functional Description CG Drives & Automation, 01-5326-01r5
Liquid cooling low level [25T]
Delay time starts counting when the fault disappears. When
the time delay has elapsed, the alarm will be reset if the
function is active.
Communication information
Liquid Cooling Low level Trip Type
[25U]
Select the preferred way to react to an alarm trip.
Communication information
Brake Fault [25V]
Delay time starts counting when the fault disappears. When
the time delay has elapsed, the alarm will be reset if the
function is active.
Communication information
Encoder [25W]
Encoder delay time, starts counting when the fault
disappears. When the time delay has elapsed, the alarm will
be reset if the function is active.
Communication information
Crane deviation [25X]
Deviation delay time, starts counting when the fault is gone.
When the time delay has elapsed, the alarm will be reset if
the function is active.
Communication information
25T LC Level
Default: Off
Off 0 Off
1–3600 1–3600 1–3600 s
Modbus Instance no/DeviceNet no: 43099
Profibus slot/index 169/3
EtherCAT and CANopen index (hex) 4c1b
Profinet IO index 19483
Fieldbus format Long, 1=1 s
Modbus format EInt
25U LC Level TT
Default: Trip
Selection: Same as menu [25B]
Modbus Instance no/DeviceNet no: 43100
Profibus slot/index 169/4
EtherCAT and CANopen index (hex) 4c1c
Profinet IO index 19484
Fieldbus format UInt
Modbus format UInt
25V Brk Fault
Default Off
Off 0 Autoreset not activated.
1 - 3600s 1 - 3600 Brake fault auto reset delay time.
Modbus Instance no/DeviceNet no: 43070
Profibus slot/index 168/229
EtherCAT and CANopen index (hex) 4bfe
Profinet IO index 19454
Fieldbus format Long, 1=1s
Modbus format EInt
25W Encoder
Default: Off
Off 0 Off
1- 3600 1- 3600 1- 3600 s
Modbus Instance no/DeviceNet no: 43561
Profibus slot/index 170/210
EtherCAT and CANopen index (hex) 4de9
Profinet IO index 19945
Fieldbus format Long, 1=1s
Modbus format EInt
25X Crane Deviat
Default: Off
Off 0 Off
1- 3600 1- 3600 1- 3600 s
Modbus Instance no/DeviceNet no: 43562
Profibus slot/index 170/211
EtherCAT and CANopen index (hex) 4dea
Profinet IO index 19946
Fieldbus format Long, 1=1s
Modbus format EInt
