CG Emotron VFX Series User Manual

CG Drives & Automation,01-5326-01r5 Functional Description 133
Release Speed [33D]
The release speed only operates with the brake function:
brake release [33C]. The release speed is the initial speed
reference during the brake release time. The torque reference
is initialized to 90% of T
NOM
to ensure that the load is held
in place.
Communication information
Brake Engage Time [33E]
The brake engage time is the time the load is held while the
mechanical brake engages. It is also used to get a firm stop
when transmissions, etc. cause “whiplash” effects. In other
words, it compensates for the time it takes to engage a
mechanical brake.
Communication information
Wait Before Brake Time [33F]
The brake wait time is the time to keep brake open and to
hold the load, either in order to be able to speed up
immediately, or to stop and engage the brake.
Communication information
Vector Brake [33G]
Braking by increasing the internal electrical losses in the
motor.
Communication information
Brake Fault trip time [33H]
The “Brake Fault trip time” for “Brake not released”
function is specified in this menu.
Communication information
The “Brake not engaged” warning is using the setting of
parameter “Brake Engaged time [33E]”.
Fig. 104 shows principle of brake operation for fault during
run (left) and during stop (right).
33D Release Spd
Default: 0 rpm
Range: - 4x Sync. Speed to 4x Sync.
Depend on:
4xmotor sync speed, 1500 rpm for 1470
rpm motor.
Modbus Instance no/DeviceNet no: 43113
Profibus slot/index 169/17
EtherCAT and CANopen index (hex) 4c29
Profinet IO index 19497
Fieldbus format Int, 1=1 rpm
Modbus format Int, 1=1 rpm
33E Brk Engage
Default: 0.00 s
Range: 0.00–3.00 s
Modbus Instance no/DeviceNet no: 43114
Profibus slot/index 169/18
EtherCAT and CANopen index (hex) 4c2a
Profinet IO index 19498
Fieldbus format Long, 1=0.01 s
Modbus format EInt
33F Brk Wait
Default: 0.00 s
Range: 0.00–30.0 s
Modbus Instance no/DeviceNet no: 43115
Profibus slot/index 169/19
EtherCAT and CANopen index (hex) 4c2b
Profinet IO index 19499
Fieldbus format Long, 1=0.01 s
Modbus format EInt
33G Vector Brake
Default: Off
Off 0
Vector brake switched off. AC drive brakes
normal with voltage limit on the DC link.
On 1
Maximum AC drive current (I
CL
) is available
for braking.
Modbus Instance no/DeviceNet no: 43116
Profibus slot/index 169/20
EtherCAT and CANopen index (hex) 4c2c
Profinet IO index 19500
Fieldbus format UInt
Modbus format UInt
33H Brk Fault
Default: 1.00s
Range 0.00 - 5.00s
Modbus Instance no/DeviceNet no: 43117
Profibus slot/index 169/21
EtherCAT and CANopen index (hex) 4c2d
Profinet IO index 19501
Fieldbus format Long, 1=0.01s
Modbus format EInt
Note: The Brake Fault trip time should be set to
longer time than the Brake release time[33C].
